DiGiCOR | Supermicro VDI Solution

VDI Solutions with NVIDIA Virtual GPU (vGPU) Software

VDI Solutions with NVIDIA Virtual GPU (vGPU) Software

NVIDIA GRID VIRTUAL GPU TECHNOLOGY

CUSTOMIZED GRAPHICS PROFILES


VDI has become increasingly popular with the broadened availability of mobile broadband, higher bandwidth, more compute power in modern mobile devices, higher display resolutions and a trend of BYOD within enterprises. Supermicro VDI solutions provide the best user experience for remote workers by leveraging NVIDIA GPUs running NVIDIA vGPU software.

NVIDIA GRID™ is the industry's most advanced technology for sharing virtual GPUs (vGPUs) across multiple virtual desktop and applications instances. You can now leverage the full power of NVIDIA data center GPUs to deliver a superior virtual graphics experience to any device, anywhere. The NVIDIA GRID platform offers the highest levels of performance, flexibility, manageability, and security—offering the right level of user experience for any virtual workflow.

IT managers can assign the optimal amount of graphics horsepower and deliver a customized graphics profile for each user. Every virtual desktop has dedicated graphics memory, just like they would at their desk, so they always have the resources they need to launch and run their applications at full performance. NVIDIA GRID lets up to sixteen users share each physical GPU, so the graphics resources of the available GPUs can be assigned to virtual machines in an the optimally balanced way.

quadro-grid-virtualization-843-u

NVIDIA GRID Virtual Applications

NVIDIA GRID Virtual Applications

For organizations deploying XenApp or other RDSH solutions. Designed to deliver PC Windows applications at full performance.
NVIDIA GRID Virtual PC

NVIDIA GRID Virtual PC

For users who want a virtual desktop, but also need a great user experience leveraging PC applications, browsers, and high-definition video
NVIDIA GRID Virtual Applications

NVIDIA GRID Virtual Workstation

For users who want to use remote professional graphics applications with full performance on any device, anywhere

NVIDIA GPUs for Virtualization

Below is a list of current GPUs that support NVIDIA virtual GPU software.

Model Picture GPU CUDA cores Memory Size Use Cases
NVIDIA V100 Tensor Core GPU NVIDIA V100 Tensor Core GPU 1 NVIDIA Volta GPU 5,120 32 GB HBM2 High-end professional graphics users; includes use for double-precision compute workloads (3D models and design workflows, intensive CAE simulations)
NVIDIA Quadro RTX™ 8000 GPU NVIDIA V100 Tensor Core GPU 1 NVIDIA Turing GPU 4,608 48 GB GDDR6 Powerful RTX rendering platform for high-end professional graphics users (rendering and creative complex designs); includes single-precision compute workloads
NVIDIA Quadro RTX™ 6000 GPU NVIDIA V100 Tensor Core GPU 1 NVIDIA Turing GPU 4,608 24 GB GDDR6 Powerful RTX rendering platform for high-end professional graphics users (rendering and creative complex designs); includes single-precision compute workloads
NVIDIA T4 Tensor Core GPU NVIDIA V100 Tensor Core GPU 1 NVIDIA Turing GPU 2,560 16 GB GDDR6 Entry to mid-range professional graphics users including deep learning inference and rendering workloads, RTX-capable, 2 T4s are a suitable upgrade path from a single M60, or upgrade from a single P4 to a single T4
NVIDIA M10 NVIDIA V100 Tensor Core GPU 4 NVIDIA Maxwell GPUs 2,560 (640 per GPU) 32 GB GDDR5 (8 GB per GPU) Best density and performance for knowledge worker workloads

* Annual Subscription An annual subscription is active for a fixed period as defined by the terms of the subscription license. To be kept active, the license will need to be renewed at the end of the subscription period. Annual subscription includes software license and Support Updates and Maintenance Subscription (SUMS).

** Perpetual License A perpetual license allows for use of the licensed software indefinitely. Users that opt to license using this model are required to subscribe to SUMS for the first year. The SUMS subscription can renewed on a yearly basis after the expiring of the initial subscription.

Purchase is available from DiGiCOR now! If you are not sure which NVIDIA vGPU product or license to choose? Please contact us and discover how Supermicro servers with NVIDIA vGPU technology accelerate the most demanding workflows.

Supermicro VDI Server solutions with NVIDIA GPUs and NVIDIA vGPU Software

Supermicro has developed a line of fully validated server solutions featuring high performance NVIDIA GPUs, along with NVIDIA virtual GPU (vGPU) software, to address the rapidly growing Virtual Desktop Infrastructure (VDI) market.
Our VDI solutions offer best-in-class remote user experience for remote desktop and/or workstation needs by allowing workers to do their job securely from anywhere while having access to the same capabilities as if they were working from the office. Because of the increasing demand for a flexible and remote workforce, many people are finding the need for a better, faster, and greener VDI infrastructure as a major part of its remote work strategy. Supermicro is here to support the growth and scale of your virtualization infrastructure.

Supermicro VDI with NVIDIA vGPU Solution Stack

  • Support, Updates & Maintenance Subscription (SUMS)
    NVIDIA Virtual GPU Software

    GRID vApps, GRID vPC, Quadro vDWS, vComputeServer
  • Hypervisor
    SYS-1029GQ-TRT, SYS-2029U-E1CRT, SYS-2029GP-TR
  • NVIDIA GPUs
    V100, T4, and M10; and Quadro® RTX™ 6000 and RTX 8000

SuperServer 1029GQ-TRT

SYS-1029GQ-TRT
Use Case:
- Supports up to 4 NVIDIA® GPUs in 1U
- Support Active/Passive GPUs
- GPU health monitoring with Fan speed control
Processor Support
  • Dual Socket P (LGA 3647) support 2nd Gen Intel® Xeon® Scalable processors (Cascade Lake/Skylake)
  • Memory Capacity
  • 12 DIMMs; up to 3TB 3DS ECC RDIMM/LRDIMM
  • DDR4-2933MHz
  • Supports Intel® Optane™ DCPMM
  • PCI-E Expansion Slots
  • 4 PCI-E 3.0 x16 (FHFL) slots,
  • * 2 PCI-E 3.0 x16 (LP) slots (Other options available)
  • Networking
  • 2x 10GBase-T LAN ports via Intel X540
  • Drive Bays
  • 2 Hot-Swap 2.5" drive bays SAS/SATA
  • 2 Internal 2.5" SATA drive bays
  • 1 M.2
  • Power Supply
  • 2000W Redundant Titanium Level Power Supplies
  • Other
  • 2 USB 3.0 ports (rear), 1 VGA port, 1 Fast UART 16550 header
  • SuperServer 1029GQ-TRT Front SuperServer 1029GQ-TRT Back SuperServer 1029GQ-TRT Details

    SuperServer 2029U-E1CRT Front SuperServer 2029U-E1CRT Back SuperServer 2029U-E1CRT Details

    SuperServer 2029U-E1CRT

    SYS-2029U-E1CRT
    Use Case: Virtualization, Hyperconverge Storage, Cloud Computing, High End Enterprise Server
    Processor Support
  • Dual Socket P (LGA 3647) support 2nd Gen Intel® Xeon® Scalable processors (Cascade Lake/Skylake)
  • Memory Capacity
  • 24 DIMMs; up to 6TB 3DS ECC RDIMM/LRDIMM
  • DDR4-2933MHz
  • Supports Intel® Optane™ DCPMM
  • PCI-E Expansion Slots
  • 1 PCI-E 3.0 x16 slot (FH, 10.5" L)
  • 5 PCI-E 3.0 x8 slots (FH, 10.5" L)
  • 1 PCI-E 3.0 x8 slot (LP)
  • 1 PCI-E 3.0 x8 slot (internal LP)
  • Networking
  • 2x 10GBase-T LAN ports via Intel X540
  • Drive Bays
  • 24 Hot-swap 2.5" drive bays: (24 SAS3 via opt. AOC)
  • (4 hybrid ports - opt. 4 NVMe)
  • Optional 2 hot-swap 2.5" rear drive bays for SSDs;
  • Optional M.2 NVMe and SATA3 ports
  • Power Supply
  • 1000W Redundant Power Supplies Titanium Level
  • Other
  • 2 USB 3.0, 1 VGA, 1 COM via RJ453 USB 3.0 ports (2 rear, 1 Type A), 1 VGA Connector, 1 Serial header, 2 SuperDOM (Disk on Module) ports

  • Configure and Customize Now


    SuperServer 2029GP-TR

    SYS-2029GP-TR
    Use Case: Supports up to 6 GPUs
    Processor Support
  • Dual Socket P (LGA 3647) support 2nd Gen Intel® Xeon® Scalable processors (Cascade Lake/Skylake)
  • Memory Capacity
  • 16 DIMMs; up to 4TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM
  • Supports Intel® Optane™ DCPMM
  • PCI-E Expansion Slots
  • 6 PCI-E 3.0 x16 slots (FHFL)
  • 1 PCI-E 3.0 x8 (in x16) slot (LP)
  • Networking
  • 1 SIOM for flexible Networking
  • Drive Bays
  • 8 Hot-swap 2.5" SAS/SATA drive bays
  • 2 Hot-swap 2.5" SATA/NVMe drive bays
  • Power Supply
  • 2000W Redundant Power Supplies Platinum Level
  • Other
  • 2 USB 3.0 ports (rear), 1 VGA port, 1 Fast UART 16550 header
  • SuperServer 2029GP-TR Front SuperServer 2029GP-TR Back SuperServer 2029GP-TR Details


    Configure and Customize Now
